Parameter Specification
Voltage 380V/50Hz
Air Pressure 0.6-0.8MPa
Max Drilling Diameter 35mm
Total Drilling Shafts 21×3
Shaft Spacing 32mm
Spindle Speed 2840r/min
Motor Power 1.5kW×3
Drilling Length 0-2500mm
Drilling Width 0-2500mm
Machine Weight 820kg
Installation Size 3300×2500×1620mm
Packaging Size 3300×1120×1620mm
Electrical Components Chint
PLC Kewei
Drilling Rig Lisheng (Taiwan)
Guide Rail Ketai Precision Machinery
Motor Brand Huixi Qianyuan
